Alrouf Highbay Light

Alrouf Low Intensity Aircraft Warning Light

Data Sheet

Alrouf Low Intensity Aircraft Warning Light

IES File

Alrouf Low Intensity Aircraft Warning Light

Installation Manual

Warning Sign

Click the relevant product code in the table above to access the Flood Light (IES file) files and the installation instructions for your luminaire.

Product Features

High-performance and reputable brand-led chips and driver
Clear polycarbonate lens with no risk of lamp breaking for safe industry applications
Optimized aluminium alloy housing design for superior thermal management
Instant light-up with no warm-up time
No cooldown is needed before the restart
High mechanical impact resistance and ingress protection rating
Compact in size and easy to transportation

Specification

Power Consumption: 100-240W
Luminous Flux: 14,000lm to 36,000lm
Input Voltage: 100-277V~
Colour Temperature: 2700 - 6500K
IP and IK Rating: IP65 and IK08
Colour Rendering Index (Ra): 80+
L70 lumen maintenance: >50, 000 hours
Power factor: >0.95
Warranty: 5 years
Operation Temperature Range: -30°C to+50°C

Alrouf Low Intensity Aircraft Warning Light

Check out the instructions in which we explain what can be read from these graphs.

alrouf highbay light

Alrouf Low Intensity Aircraft Warning Light

alrouf highbay light

Ordering Information
Part No	Power	CCT	Flux	Dimming	Diameter	Height	Beam Angle
Alrouf-UFO-E100W	100W	2700-6500K	14,000-15,000lm	optional	247mm	163mm	60/90/120°
Alrouf-UFO-E150W	150W	2700-6500K	21,000-25,500lm	optional	294mm	174mm	60/90/120°
Alrouf-UFO-E200W	200W	2700-6500K	28,000-30,000lm	optional	320mm	188mm	60/90/120°
Alrouf-UFO-E240W	240W	2700-6500K	33,600-36,000lm	optional	320mm	188mm	60/90/120°

Model	Carton Size	N.W	G.W	QTY
Alrouf-UFO-E100W	280280170mm	2.2KG	2.7KG	1PCS
Alrouf-UFO-E150W	330330180mm	3.0KG	3.5KG	1PCS
Alrouf-UFO-E200W	350350200mm	3.8KG	4.2KG	1PCS
Alrouf-UFO-E240W	350350200mm	3.8KG	4.2KG	1PCS
