Alrouf Led Flood Light N Series
Click the relevant product code in the table above to access the Flood Light (IES file) files and the installation instructions for your luminaire.
Check out the instructions in which we explain what can be read from these graphs.
Manual
| SP-N1xxxW XYZP |
SP-N2xxxW XYZP |
| Input Voltage |
AC100-277V/AC200-240V |
Input Voltage |
AC100-277V/AC200-240V |
| Power |
250W/300W/350W |
Power |
400W/500W/600W |
| Efficiency |
130lm/W，150lm/W |
Efficiency |
130lm/W，150lm/W |
| Intelligent Control |
0-10V Dimming/DMX512/DALi |
Intelligent Control |
0-10V Dimming/DMX512/DALi |
| Power Factor |
0.95 |
Power Factor |
0.95 |
| Surge Protection |
10KV |
Surge Protection |
10KV |
| LED Chip |
3030/5050 |
LED Chip |
3030/5050 |
| Driver |
Sosen/Inventronics/Meanwell |
Driver |
Sosen/Inventronics/Meanwell |
| CCT |
4000K/5000K/6500K |
CCT |
4000K/5000K/6500K |
| CRI |
70/80 |
CRI |
70/80 |
| Beam Angle |
15°/45°/60°/90°/120°/T30x90/T3VS/T2VS |
Beam Angle |
15°/45°/60°/90°/120°/T30x90/T3VS/T2VS |
| Working Temperature |
-400C - +55 0C/+900C（Remoted Driver） |
Working Temperature |
-40 0C - +550C/+900C（Remoted Driver） |
| Housing Material |
ADC12 Aluminum |
Housing Material |
ADC12 Aluminum |
| Rating |
IK08/IP66/Class I |
Rating |
IK08/IP66/Class I |
| Lifespan |
50,000 Hours |
Lifespan |
50,000 Hours |
| Warranty |
5 Years/3 Years |
Warranty |
5 Years/3 Years |
| Net Weight |
7.8Kg(17.2Ibs) |
Net Weight |
16Kg(35.3Ibs) |
| Gross Weight |
10.2Kg(22.5Ibs) |
Gross Weight |
20.2Kg(44.5Ibs) |
| Packing Size |
535x392x213mm(21.1x15.4x8.4inch) |
Packing Size |
590x585x245mm(23.2x23.0x9.6inch) |
| Model NO. |
SP-N3xxxW XYZP |
SP-N4xxxW XYZP |
SP-N5xxxW XYZP |
| Input Voltage |
AC100-277V/AC200-240V |
AC100-277V/AC200-240V |
AC100-277V/AC200-240V |
| Power |
700W/750W/800W/900W/1000W |
1000W/1100W/1200W/1400W |
1250W/1400W/1500W/1750W |
| Efficiency |
130lm/W，150lm/W |
130lm/W，150lm/W |
130lm/W，150lm/W |
| Intelligent Control |
0-10V Dimming/DMX512/DALi |
0-10V Dimming/DMX512/DALi |
0-10V Dimming/DMX512/DALi |
| Power Factor |
0.95 |
0.95 |
0.95 |
| Surge Protection |
10KV |
10KV |
10KV |
| LED Chip |
3030/5050 |
3030/5050 |
3030/5050 |
| Driver |
Sosen/Inventronics/Meanwell |
Sosen/Inventronics/Meanwell |
Sosen/Inventronics/Meanwell |
| CCT |
4000K/5000K/6500K |
4000K/5000K/6500K |
4000K/5000K/6500K |
| CRI |
70/80 |
70/80 |
70/80 |
| Beam Angle |
15°/45°/60°/90°/120°/T30x90/T3VS/T2VS |
15°/45°/60°/90°/120°/T30x90/T3VS/T2VS |
15°/45°/60°/90°/120°/T30x90/T3VS/T2VS |
| Working Temperature |
-400C - +550C/+90 0C（Remoted Driver） |
-400C - +550C/+900C（Remoted Driver） |
-400C - +550C/+900C（Remoted Driver） |
| Housing Material |
ADC12 Aluminum |
ADC12 Aluminum |
ADC12 Aluminum |
| Rating |
IK08/IP66/Class I |
IK08/IP66/Class I |
IK08/IP66/Class I |
| Lifespan |
5 Years |
5 Years |
50,000 Hours |
| Warranty |
50,000 Hours/3 Years |
50,000 Hours/ 3 Years |
5 Years/3 Years |
| Net Weight |
22.7Kg(50.0Ibs) |
34Kg(75.0Ibs) |
41Kg(90.4Ibs) |
| Gross Weight |
28.5Kg(62.3Ibs) |
39.3Kg(86.6Ibs) |
47.5Kg(104.7Ibs) |
| Packing Size |
799x585x245mm(31.5x23.0x9.6inch) |
1021x585x245mm(40.2x23.0x9.6inch) |
1231x585x245mm(48.5x23.0x9.6inch) |
