Alrouf Street Light Free Die Cast
Click the relevant product code in the table above to access the Flood Light (IES file) files and the installation instructions for your luminaire.
Product Features
- System Light efficacy 140 LPW.
- Rugged one-piece die cast housing with corrosive resistant polyester powder coat finish body.
- Multiple choices of optical lenses for true type and type street lighting patterns.
- Tool-free access for easy installation, direct slide-in mount.
- IP66 is water and dust-proof.
- 3G Vibration & IK08 impact resistance.
- 5-10 Years Warranty.
Performance
- Philips Lumileds
- 10W~200W
- 4500~5500K (2500~6500K Optional)
- ≥70
- L70>100,000hours
- AC 100~277V
- 0.95 min
- IP66
- IK08
- 80x150° / 85x155° / 90x150° / 100x150°
- Operating Temperature:-45°C to +45°C (-49°F to 113°F)
- Storing Temperature:-45°C to +80°C (-49°F to 176°F)
- 132lm/W~145lm/W
- 3G Vibration
- Inventronics / Sosen
Check out the instructions in which we explain what can be read from these graphs.
Manual
| Typical model specification |
| Part # |
Power |
LEDs Qty |
Lens Qty |
Out Current (Each Chis) |
Efficacy(IES) |
Total Lumens |
N.W |
Product Dimension |
|
10W |
24 |
2 |
63mA |
145lm/w |
1450lm |
|
577x233x103mm 22.7x9.2x4.1in |
|
20W |
32 |
2 |
95mA |
140lm/w |
2800lm |
|
| ALROUF-STL |
30W |
48 |
4 |
95mA |
140lm/w |
4200lm |
4.0kg/8.8lbs |
|
40W |
60 |
4 |
102mA |
140lm/w |
5600lm |
|
|
50W |
60 |
4 |
125mA |
135lm/w |
6750lm |
|
|
60W |
72 |
6 |
125mA |
137lm/w |
8220lm |
|
627x272x103mm 24.7x10.7x4.1in |
|
70W |
96 |
6 |
112mA |
143lm/w |
10010lm |
4.0kg/8.8lbs |
| ALROUF-STL |
80W |
96 |
6 |
126mA |
140lm/w |
11200lm |
|
|
90W |
96 |
6 |
145mA |
137lm/w |
12330lm |
5.0kg11.0lbs |
|
100W |
96 |
6 |
155mA |
135lm/w |
13500lm |
|
110W |
112 |
7 |
152mA |
132lm/w |
14520lm |
|
627x272x103mm 24.7x10.7x4.1in |
|
120W |
144 |
9 |
130mA |
142lm/w |
17040lm |
|
| ALROUF-STL |
130W |
144 |
9 |
140mA |
139lm/w |
18070lm |
5.0kg11.0lbs |
|
140W |
144 |
9 |
150mA |
137lm/w |
19180lm |
|
|
150W |
144 |
9 |
155mA |
135lm/w |
20250lm |
|
|
160W |
192 |
12 |
130mA |
137lm/w |
21920lm |
6.0kg13.2lbs |
767x300x103mm 30.2x11.8x4.1in |
|
170W |
240 |
16 |
112mA |
140lm/w |
23800lm |
|
| ALROUF-STL |
180W |
240 |
16 |
120mA |
138lm/w |
24840lm |
6.5kg14.3lbs |
|
200W |
240 |
16 |
130mA |
135lm/w |
27000lm |
|
