Product Description

LED Emergency Lights are indoor safety luminaires installed in corridors, offices, schools, and commercial buildings to provide evacuation lighting during power failure.
Model BY-Z3125A2 operates in continuous lighting mode and switches to battery during outages, providing different emergency durations depending on selected brightness level.

This model is typically used for corridor lighting layouts where uniform evacuation lighting is required.

Engineering Performance and Technology

Model: BY-Z3125A2

  • Continuous operation mode during normal power
  • Emergency duration options:
  • High mode: about 3 hours
  • Low mode: about 6 hours
  • Emergency illumination levels:
  • High mode: about 270 lumens
  • Low mode: about 110 lumens
  • LED SMD light source
  • Lithium battery 3.7 V, 1200 mAh × 2
  • Recharge time about 24 hours
  • Protection rating IP20 for indoor dry areas
  • Operating temperature range 0 °C to 40 °C

Selectable brightness allows adjusting emergency duration according to corridor length and illumination requirement.

Why This Type of Emergency Light Is Used

  • Provides continuous corridor lighting with backup during power failure
  • Adjustable emergency duration for different project requirements
  • Suitable for indoor evacuation lighting layouts
  • Stable lithium battery performance
  • Compatible with commercial building lighting plans

 Typical Applications

  • Office corridors
  • Schools and universities
  • Hospitals and clinics
  • Shopping malls
  • Hotels and public buildings

FIXING TYPE

  • CEILING RECESSED
  • CEILING SURFACED
  • SEMI RECESSED
  • HANGING WITH CHAIN

LEGEND OPTINS

  • EMERGENCY (ENGLISH & ARABIC)
  • EXIT (ENGLISH & ARABIC)
  • RUNNING DIRECTION WISE
  • CUSTOM MADE

 Compliance and Project Suitability

This emergency light is suitable for indoor commercial buildings in Saudi Arabia, where maintained emergency lighting is required for corridors and evacuation routes.

What is the emergency duration of this model?
The light provides about 3 hours in high mode and about 6 hours in low mode.

What is the emergency illumination level?
Approximately 270 lumens in high mode and 110 lumens in low mode.

Is the light maintained or non-maintained?
This model operates in continuous lighting mode.

What battery type is used?
Lithium batteries 3.7 V 1200 mAh × 2.

Explore more certified emergency lighting solutions from Al Rouf LED designed for commercial and industrial safety applications. For technical support, product recommendations, or project quotations, contact our team to help you select the right emergency lighting system for your project.
