Final Approach and Take Off Area Light – ART-HP-I-FATO (L)


Warning Sign
Click the relevant product code in the table above to access the Flood Light (IES file) files and the installation instructions for your luminaire.

Installation

The ART-HP-I-FATO (L) is a dedicated Final Approach and Take Off Area (FATO) light designed for helicopter landing areas.
It features a cast aviation aluminum housing combined with an SMT LED light source and an optical glass structure.
The control circuit is equipped with lightning and surge protection, enabling use in harsh operating environments.

Key Technical Features

  • High-strength cast aviation aluminum housing with fully sealed structure.
  • SMT LED light source with optical glass structure.
  • Optical system designed to meet ICAO and GACA light distribution requirements.
  • Control circuit with integrated lightning and surge protection.
  • Adoption of high thermal conductive coating technology for heat dissipation.
  • Resistance to impact, lightning, sunlight, snow, typhoons, hail, and severe weather.
  • Over-current protection function.
  • Industrial operating temperature range from -40°C to +55°C.
  • Protection grade: IP66 / IP68 (depending on installation conditions).

Application Environment

  • Ground helipads
  • Steel helipads
  • Rooftop helipads
  • Ship helipads
  • Emergency rescue helipads
  • Military helipads
  • UAV helipads
  • Low-altitude flight fields
No ACF gallery field data found
Check out the instructions in which we explain what can be read from these graphs.
Manual

Technical Specifications

  • Light Type: Final Approach and Take Off Area Light
  • Model: ART-HP-I-FATO (L)
  • Light Source: LED
  • Emitted Color: White
  • Working Mode: Steady Light
  • Average Power Consumption: ≤9.5 W
  • Housing Material: Aluminum Alloy
  • Light Source Lifespan: ≥200,000 hours
  • Surge Protection Rating: 3KA
  • Operating Temperature: -40°C to +55°C
  • Wind Load Resistance: Up to 240 km/h
  • Operating Altitude: ≥5500 m

Standards & Compliance

  • ICAO Annex 14 – Volume I (8th Edition)
  • GACA MH 5001-2013 & AC-137-CA-2017-01-R1
  • FAA Advisory Circular 150/5345-43J

For pricing, technical datasheets, or to evaluate whether ART-HP-I-FATO (L) is
suitable for your project, please contact Alrouf Lighting Technology
