Types of Occupancy Sensors for Lighting: A Selection Guide

The main types of occupancy sensors for lighting are passive infrared (PIR), ultrasonic, radar-based and dual-technology sensors. They detect activity differently, so the right choice depends on room layout, occupant movement, mounting position and the required lighting response.

For a Saudi office, villa or commercial project, start with how people use the space. Detecting someone walking through a corridor is a different task from keeping lights on for a person working quietly at a desk.

What Does an Occupancy Sensor Do?

An occupancy sensor detects activity that a lighting system uses to control connected lights. Depending on the configuration, detection can trigger switching, maintain illumination or initiate a dimming sequence.

An adjustable delay usually determines what happens after activity is no longer detected.

Occupancy detection does not automatically mean reliable detection of a completely stationary person. Check the model’s documented performance for the expected activity.

For more on the terminology, read occupancy sensors vs motion sensors.

What Are the Main Types of Occupancy Sensors?

Sensor technologyHow it detects activityMain selection consideration
PIRDetects changes in infrared energy as people move through its coverage zonesClear view of occupants and suitable movement coverage
UltrasonicDetects movement through changes in reflected high-frequency soundSmall-motion performance and sensitivity to disturbances
Radar-basedUses transmitted radio signals and their reflectionsDetection boundaries and model-specific capabilities
Dual technologyCombines two detection methodsThe logic used to activate and maintain lighting

1. Passive Infrared: PIR Occupancy Sensors

A PIR occupancy sensor detects changes in infrared energy across its detection zones. It needs a clear view of the monitored activity; partitions, shelving and furniture can obstruct coverage.

PIR is an option for entrances, corridors, storage rooms and other areas with regular movement. For seated work, check minor-motion coverage rather than relying only on the maximum detection distance.

Before selecting a model, review:

  • Mounting height and coverage diagram.
  • Expected walking and seated activity.
  • Obstructions within the space.
  • Sensitivity and switch-off delay.

2. Ultrasonic Occupancy Sensors

Ultrasonic sensors transmit high-frequency sound and monitor reflected signals for movement. They can detect small movements and provide coverage around some obstructions.

They are an option to evaluate for partitioned rooms and similar layouts. However, environmental movement and detection beyond the intended area can cause unwanted operation.

Assess room boundaries, ventilation conditions and sensitivity during commissioning.

3. Radar-Based Occupancy Sensors

Radar-based sensors use radio signals to detect activity. Their performance depends on the frequency, antenna design and signal processing used by the specific device.

Some detect general movement; others have documented sensitivity to smaller movements. Do not assume that every radar sensor provides the same stationary-presence detection.

Check the intended detection zone and test activity in neighbouring spaces to identify unwanted triggering.

4. Dual-Technology Occupancy Sensors

Dual-technology sensors combine two detection methods, commonly PIR and ultrasonic.

The important question is how those methods work together. A device may require both technologies to detect activity before switching lights on, while allowing either technology to maintain illumination.

Review the manufacturer’s control logic rather than assuming all dual-technology devices behave alike.

Is a Wireless Occupancy Sensor a Different Sensor Type?

Wireless describes communication, while PIR, ultrasonic and radar describe detection.

A sensor can therefore be both PIR and wireless. Its power supply is another separate characteristic: wireless communication does not necessarily mean battery operation.

For a retrofit project, check:

  • Communication protocol and compatible controller.
  • Power supply and maintenance access.
  • Coverage between the sensor and receiving device.
  • Supported switching or dimming functions.

Explore Alrouf’s smart lighting solutions to discuss compatible sensor and controller combinations.

Does PIR + Lux Mean Dual-Technology Detection?

Not in the PIR-plus-ultrasonic sense described above.

PIR + Lux combines movement detection with light-level measurement. The movement sensor detects activity, while the light-level function helps determine whether artificial lighting is needed.

Also distinguish between:

  • Light-level switching: permitting or preventing activation according to a threshold.
  • Daylight-responsive dimming: adjusting output as available daylight changes.

A lux sensor alone does not establish that the complete system supports continuous daylight dimming. Confirm the controller, output interface and configuration.

Which Sensor Options Appear in Alrouf’s Catalogue?

Alrouf’s 2026 lighting control catalogue includes the following examples:

ModelCatalogue-listed optionKey details
H2RF PIR sensorRecessed installation; RF 433 MHz; adjustable detection range listed as 0–8 m
H4Battery-powered RF PIR sensorExternal mounting; RF 433 MHz; light-level, sensitivity and time settings
H3Radar-based human body sensorRecessed installation; adjustable sensitivity, light threshold and time delay
H2-CAS-BCasambi ceiling PIR sensorBattery-powered; PIR + Lux sensing; listed 360° detection angle
H6-CAS-V-SFixture-mounted Casambi PIR sensorPIR + Lux sensing; DC 12–24V supply; 0–10V output

These are catalogue examples, not interchangeable devices. Confirm the exact model, current availability, compatible equipment and installation requirements before specification.

The ultrasonic and dual-technology sections explain general market options; they do not establish that those products are included in Alrouf’s range.

Download the lighting control catalogue.

How Do You Choose an Occupancy Sensor for Your Room?

Choose against the activity and installation, not detection distance alone.

ApplicationWhat to verify
Corridor or entranceDetection of approaching occupants and coverage at access points
Office or meeting roomMinor-motion detection at desks and seated positions
Partitioned spaceCoverage gaps caused by screens, furniture or cubicles
Daylit roomLight-level settings and the required switching or dimming behaviour
Existing buildingWiring, power supply, receiver compatibility and maintenance access

Agree on the operating sequence before ordering: what turns the lights on, how long they remain on and what happens when a person uses a manual switch.

Compatible wireless kinetic switches may provide manual control points within a suitable configuration.

Frequently Asked Questions

What is the difference between occupancy and vacancy operation?

Occupancy operation typically provides automatic switching on and off. Vacancy operation requires manual switching on and provides automatic switching off. These are control modes, not detection technologies.

Read our occupancy vs vacancy sensor guide for more detail.

Which occupancy sensor is best for an office?

Select a model with documented minor-motion performance for seated work. Check partitions, mounting height and coverage, then test it under normal working conditions.

Can one sensor cover an entire room?

Possibly. The answer depends on the coverage pattern, mounting position, obstructions and occupant activity. A stated maximum range does not guarantee complete room coverage.

Do occupancy sensors save electricity?

They can reduce unnecessary lighting operation. Actual savings depend on room usage, existing controls, lighting load and the selected settings.

Discuss Your Sensor Requirements with Alrouf

Send your room layouts, ceiling heights, expected activities and required lighting sequence. Include existing controllers, LED driver details and any preferred communication platform.

Contact Alrouf to discuss catalogue-listed sensors and compatible lighting control systems for your project.
